Electronics
Delay Lines Compared: Coaxial, Acoustic, Digital and Fiber Optic Options for RF Systems
| Key Takeaways
• A delay line holds back an RF signal for a precise time and is used for radar and altimeter testing, signal-path alignment, phased-array beamforming and signal processing. • The four main delay line families are coaxial cable, acoustic (SAW and BAW), digital (ADC, memory and DAC) and fiber optic. • Coax and fiber add a similar delay of roughly 4 to 5 ns per meter, but single-mode fiber loses well under 1 dB per kilometer regardless of RF frequency, while coax loss rises with length and frequency. • Emulating a radar target at 10 km needs about 66 microseconds of round-trip delay, or roughly 13.6 km of single-mode fiber. |
What is a delay line?
A delay line is a component that holds back an RF or microwave signal for a precise, known amount of time and then releases it otherwise unchanged. Delay lines are used to emulate distance in radar and altimeter testing, to align the timing of parallel signal paths, to build true-time-delay beamformers for phased arrays and to provide short-term signal memory in correlators and receivers.
In radar work the delay always represents a round trip, which makes the numbers grow quickly. A SPIE conference paper comparing microwave analog delay line technologies points out that emulating a target only 50 m away already calls for 333.33 ns of delay, because the signal has to travel out and back. For readers who want the underlying vocabulary first, a broader primer on delay lines covers the terms used throughout this comparison.
What types of delay line are available?
There are four main families of RF delay line: coaxial cable, acoustic (surface or bulk acoustic wave), digital, and fiber optic. Each creates delay in a physically different way, and that physical mechanism determines its loss, bandwidth, size and flexibility.
| Technology | How the delay is created | Main strengths | Main limitations |
| Coaxial cable | The RF signal travels through a coiled length of coax, often semi-rigid | Simple, passive, no signal conversion | Bulky at long delays; loss rises with length and frequency |
| Acoustic (SAW / BAW) | RF is converted into an acoustic wave in a piezoelectric material, which travels far slower than an electromagnetic wave | Very compact for a given delay | High insertion loss, reported above 30 dB; SAW limited to roughly 2.5 GHz |
| Digital | The signal is sampled by an ADC, held in memory and regenerated by a DAC | Delay is programmable and can be combined with synthetic Doppler or modulation | Bandwidth and spurious performance set by the converters; adds latency of its own |
| Fiber optic (ODL) | RF is modulated onto light and delayed by a chosen length of single-mode fiber | Low loss that does not change with RF frequency; delays from nanoseconds to milliseconds | Requires optical conversion, which adds noise; each delay value needs its own fiber length or a switch path |
How do coaxial delay lines compare with fiber optic delay lines?
Coax and fiber produce a similar delay per meter, around 4 to 5 nanoseconds depending on the cable dielectric, but fiber achieves it with a tiny fraction of the loss. Standard G.652.D fiber has a group index close to 1.468, which works out to roughly 4.9 ns of delay per meter, or about 4.9 microseconds per kilometer.
The difference shows up in attenuation. A microsecond of delay needs roughly 200 m of either medium. Published attenuation tables put even thick 7/8-inch hardline at about 2.1 dB per 100 feet at 2.4 GHz, which means close to 14 dB of loss over 200 m, and thinner coax several times more. The same 200 m of single-mode fiber loses well under 0.1 dB of optical power. Just as important, the fiber loss is set by the optical wavelength rather than by the RF carrier riding on it, so the fiber in a fiber optic delay line contributes the same loss at 1 GHz as at 18 GHz, while a coax delay line becomes progressively lossier as frequency rises.
Longer delays make the gap decisive. The chart below shows how much fiber a radar test needs to emulate targets at different ranges. A 10 km target already requires about 13.6 km of fiber, a length no coax delay line could realistically match.

When do acoustic or digital delay lines make more sense?
Acoustic delay lines make sense when space is tight and the signal sits below a few gigahertz, and digital delay lines make sense when the delay must change continuously or the test needs synthetic signal effects. Acoustic devices exploit the fact that a mechanical wave in a piezoelectric crystal moves far more slowly than an electromagnetic wave, so a long delay fits in a small package. The cost is high insertion loss and, for surface acoustic wave parts, an upper frequency limit of around 2.5 GHz; bulk acoustic wave technology extends the achievable delay range.
A university study of wideband delay lines for automotive radar compares these approaches for a target simulator that needed an 800 MHz bandwidth and delays tunable from 1.3 ns to 1.67 microseconds, a useful example of how bandwidth and delay range together narrow the technology choice. Fully digital delay lines take a different route: an analog-to-digital converter samples the signal, memory holds it, and a digital-to-analog converter regenerates it. That flexibility is valuable, but instantaneous bandwidth, dynamic range and spurious content all depend on the converters.
What is the difference between fixed, variable and progressive delay lines?
A fixed delay line provides one delay value, while a variable delay line lets the user switch between several delays; a progressive delay line is a variable design that combines a small set of fiber spools in different combinations to produce many more delay values than it has spools. A passive optical delay line is simply a coil of fiber cut to an exact length and needs no power; in an RF system it sits between an optical transmitter and receiver.
Progressive designs typically use cascaded optical switch matrices. Four 2×2 optical switches can select 16 different delays, and eight binary-weighted spools can produce 255 distinct non-zero combinations. Variable, progressive and passive optical delay line architectures are explained in more detail, including how dispersion compensation and optical amplification are added when delays become very long.
How should an engineer choose a delay line?
Start from the application’s frequency range and maximum delay, then check loss, noise and switching requirements against each technology. The following criteria narrow the choice quickly:
- Frequency range: acoustic devices suit lower bands, while coax and fiber cover microwave frequencies and fiber holds its loss steady across them.
- Maximum delay and resolution: delays beyond a few hundred nanoseconds favor fiber; fine, continuously adjustable steps favor digital or switched designs.
- Insertion loss and noise figure: acoustic parts lose the most signal, while optical links trade a fixed conversion loss for nearly flat loss with length.
- Signal purity: phase noise and spurious content matter for radar and altimeter testing, where the delayed signal must look exactly like a real echo.
- Switching and control: test benches often need several delay values selectable from a front panel or remotely.
For signal-purity questions in optical designs, an application note on phase noise and RF amplification in ODL systems covers how amplifier placement affects the delayed signal. For catalog-level comparison of ranges and switch configurations, fiber optic delay line hardware shows how commercial units package these options into rack-mount systems.
Frequently Asked Questions
What is a delay line used for?
A delay line holds back an RF signal for a precise time, which is used to emulate target distance in radar and altimeter testing, align signal paths, steer phased-array beams and store signals briefly for processing.
How much delay does one meter of optical fiber add?
One meter of standard single-mode fiber adds roughly 4.9 nanoseconds of delay, based on a group index of about 1.468.
Why are fiber optic delay lines preferred for long delays?
Fiber optic delay lines are preferred for long delays because single-mode fiber loses well under 1 dB per kilometer and that loss does not change with the RF frequency being delayed, while coaxial cable loss grows with both length and frequency.
What is a progressive delay line?
A progressive delay line combines a small set of fiber spools through optical switches so that many delay values can be selected; eight binary-weighted spools can produce 255 different non-zero delays.
Electronics
Military PCB Manufacturer Checklist: What Each Credential Actually Verifies
| Key Takeaways
• MIL-PRF-31032 qualifies a manufacturer’s process and quality plan through the Defense Logistics Agency’s Qualified Manufacturers List rather than approving individual part numbers. • IPC Class 3 defines high-reliability board performance, and IPC-6012DS adds requirements for rigid boards used in space and military avionics. • AS9100 is the aviation, space and defense quality management standard built on ISO 9001, and certified suppliers are listed in the IAQG’s OASIS database. • U.S. manufacturers of defense articles must register with the State Department’s Directorate of Defense Trade Controls under ITAR, even if they do not export. |
What makes a military PCB manufacturer different from a standard board shop?
A military PCB manufacturer is distinguished less by the boards it builds than by the evidence it can show: qualification against defense performance requirements, an aviation-grade quality system, and compliance with U.S. export controls. The boards themselves often overlap with commercial high-reliability designs, since the defense specification sheets cover rigid multilayer, single- and double-sided, flexible, rigid-flex and high-frequency constructions. What changes is the proof behind them. Buyers comparing suppliers for requirements that are specific to defense electronics usually end up checking four things: the military performance specification, the IPC class, the quality certification and the export registration.
What do IPC Class 3 and IPC-6012DS add to a military board specification?
IPC Class 3 is the high-reliability performance tier in IPC’s printed board standards, and IPC-6012DS is an addendum that adds requirements for rigid boards used in space and military avionics. The addendum is aimed at boards that must survive the vibration, ground testing and thermal cycling of those environments, and it supplements or replaces selected requirements in IPC-6012D. Thermal cycling is also why accelerated thermal testing is relevant to these boards, and one manufacturer describes an in-house accelerated thermal shock lab built to evaluate board survivability. For flexible boards, a trade-press column reports that IPC-6013 Class 3 is generally accepted by government agencies as the commercial equivalent of the military specification.
What does MIL-PRF-31032 actually qualify?
MIL-PRF-31032 is the Department of Defense performance specification for printed boards, and it qualifies the manufacturer’s process and quality plan rather than individual part numbers. Certification runs through the Defense Logistics Agency’s Qualified Manufacturers List program, which requires verification of the quality management plan by a Technical Review Board, demonstrated manufacturing capability and ongoing lot acceptance testing. Manufacturers that complete the process are listed on the QML, which defense contractors use when selecting suppliers for new programs.
DLA’s own certification language adds two cautions: a QML listing does not guarantee acceptance of a product in any future purchase, and it does not waive any requirement of the specification. The certification letter also details which technologies a manufacturer is approved for, so the listed scope matters as much as the listing itself.
What would a MIL-PRF-31032 cancellation change for buyers?
A cancellation would move board performance requirements toward IPC standards fairly directly, but it would not automatically replace the qualification system around them. An April 2026 column reported that a Defense Logistics Agency memorandum dated March 4, 2026 proposed cancelling MIL-PRF-31032 and its six specification sheets, with a short comment window and a path for another activity to accept management of the documents. The column describes both the proposal and the questions it raises about the QML. Its author notes that the IPC-6010 series already serves as the commercial counterpart, while the QML, the Technical Review Board model and the DLA oversight role would need deliberate redesign by whoever takes ownership.
The column also asks what happens to legacy programs that still cite MIL-PRF-31032 or the older MIL-PRF-55110, which remains in use on some older platforms. The final outcome was not confirmed in the sources reviewed for this article, so it should be checked with the qualifying activity or the contracting officer before a purchasing decision relies on it.

What does AS9100 certification tell a buyer?
AS9100 shows that a supplier operates a quality management system built for aviation, space and defense work, and it is based on ISO 9001 with additional industry requirements. The standards are published through the International Aerospace Quality Group, which also runs the certification scheme and maintains the Online Aerospace Supplier Information System, known as OASIS. That database holds certification status, auditor information and audit results, so a buyer can check a supplier’s claim directly rather than relying on a logo. Details of the scheme are on the IAQG certification overview.
Does a PCB manufacturer need ITAR registration?
Any U.S. company that manufactures defense articles must register with the State Department’s Directorate of Defense Trade Controls, even if it never exports. The registration form’s own instructions state that manufacturers who do not export must nevertheless register under ITAR section 122.1. The relevant instructions are in the State Department DS-2032 registration form. Registration is a legal requirement for certain work, not a quality credential, so it answers a different question from the other items on this list.
How do the main credentials compare side by side?
The table below summarizes what each item covers and where a buyer can check it. The checking column matters most, because each credential has its own source of truth.
| Credential | What it covers | Who administers it | Where to check |
| MIL-PRF-31032 | Performance and verification requirements for printed boards under a QML program | Defense Logistics Agency | DLA certification letter and QML listing; confirm current status |
| IPC-6012 / IPC-6013 Class 3 | Performance requirements for rigid and flexible boards at the high-reliability tier | IPC | Supplier conformance records and purchase documents |
| IPC-6012DS | Added requirements for rigid boards in space and military avionics | IPC | Called out in the drawing or purchase order |
| AS9100 | Quality management for aviation, space and defense organizations | IAQG scheme and certification bodies | IAQG OASIS database |
| ITAR registration | Registration of manufacturers of defense articles | State Department DDTC | Evidence of current registration from the supplier |
How should a buyer verify what a supplier claims?
A buyer should verify each credential at its source and treat a supplier’s published sector experience as context rather than proof. Some suppliers publish more than others. PCB Technologies, for example, describes defense experience that includes special antennas, seekers, night vision equipment, radios, data terminals, radiation detectors and range finders, which tells a buyer what kinds of programs a supplier has touched but not which certifications it holds.
- Ask for the DLA certification letter and the qualified technology scope, and compare it to the board being quoted.
- Look the supplier up in OASIS and confirm the certification body, scope and expiry.
- Confirm which IPC class and addendum the drawing actually requires, and ask for the matching test records.
- Ask for evidence of current ITAR registration if the work involves defense articles.
- Re-check the MIL-PRF-31032 status, since the specification was proposed for cancellation in 2026.
Frequently Asked Questions
What is a QML in military PCB sourcing?
A Qualified Manufacturers List is a Defense Logistics Agency listing of manufacturers whose processes and quality plans have been qualified under MIL-PRF-31032, which lets defense buyers source boards from verified suppliers.
Is IPC Class 3 the same as MIL-PRF-31032?
No. IPC Class 3 is a high-reliability performance tier, while MIL-PRF-31032 is tied to a government qualification program for the manufacturer, although a trade-press column notes that IPC-6013 Class 3 is generally accepted as the commercial equivalent for flexible boards.
Does a U.S. PCB manufacturer that does not export need ITAR registration?
Yes, if it manufactures defense articles, because the State Department’s registration instructions say manufacturers who do not export must still register.
How can a buyer check a supplier’s AS9100 certification?
A buyer can search the International Aerospace Quality Group’s OASIS database, which lists certification status, auditor information and audit results for certified suppliers.
Electronics
GPS Over Fiber: How Buildings Get Precise Timing Signals Indoors
Buildings, tunnels, and parking structures block GPS satellite signals from reaching the devices that depend on them for precise timing. Distributing a single rooftop GPS signal to many indoor locations without losing accuracy is a common, and often underestimated, engineering problem. This piece walks through how GPS over fiber distribution solves it, in plain question-and-answer form.
Why can’t you just run coax to every timing device?
Coaxial cable loses signal strength as it gets longer, and that loss gets worse at higher frequencies. GPS signals sit up near 1.5 GHz, a range where coax attenuation climbs quickly. Once a cable run stretches beyond roughly a hundred feet, the accumulated loss can degrade the signal below what a receiver needs to lock onto it reliably.

Nominal coax attenuation rises steeply with frequency, while fiber optic loss stays comparatively flat and low (illustrative, not a specific product measurement).
How does the fiber-based alternative work?
A rooftop GPS antenna feeds a transmitter module that converts the incoming satellite signal onto an optical carrier. That optical signal travels over low-loss fiber, and can be split to reach many destinations at once using standard optical splitters, before a fiber optic transmitter and receiver pair converts each branch back to an RF GPS signal at its endpoint. Because a single donor antenna can feed dozens of splits, one rooftop receiver can serve timing devices scattered across an entire facility.
What actually needs this kind of precise timing?
Data centers rely on GPS timing to keep distributed systems synchronized. Financial networks use it to timestamp transactions consistently across locations. Highway tunnels sometimes need GPS re-radiated inside for emergency vehicle navigation. In each case the requirement is the same: get an accurate, undistorted GPS signal to a location the satellite signal itself can’t reach directly.
How precise does GPS timing actually get?
According to the U.S. government’s official GPS information site, GPS time transfer is commonly used to synchronize clocks and networks to Coordinated Universal Time, with a typical accuracy relative to the U.S. Naval Observatory’s time standard of 30 nanoseconds or better, 95 percent of the time, when using a dedicated time-transfer receiver. See GPS.gov’s overview of GPS timing applications for more detail on how that precision is used across industries.
Frequently Asked Questions
Why does GPS signal distribution need fiber instead of just more coax?
Coax loss increases sharply at GPS frequencies, so runs longer than about a hundred feet start to degrade signal quality. Fiber optic loss stays low over much longer distances.
Can one GPS antenna really serve an entire building?
Yes. Once the signal is converted to an optical carrier, it can be split many times using standard optical splitters, letting a single rooftop antenna feed numerous indoor endpoints.
What industries rely most on distributed GPS timing?
Data centers, financial networks, and telecommunications infrastructure are common users, since all depend on precise, synchronized time across multiple locations.
Electronics
QFN Packages Explained: Types, Benefits, and Panel-Level Innovations
Among the most widely used IC packages in modern electronics, QFN packages have earned their place in product designs ranging from Bluetooth chips to automotive radar modules. Compact, thermally efficient, and electrically clean, QFN (Quad Flat No-Lead) packages offer a compelling combination of performance and manufacturability. But not all QFN packages are equal — and the differences between standard, organic, and panel-level variants can significantly affect both product performance and production economics.
This article breaks down the key QFN package types, explores their respective advantages, and explains how advances in panel-level packaging are reshaping the economics of high-volume production.
What Is a QFN Package?
QFN stands for Quad Flat No-Lead — a surface-mount package format where leads are located on the underside of the package rather than extending outward. A large exposed pad on the package bottom provides a direct thermal path to the PCB, making QFN one of the most thermally efficient small-form-factor package types available.
The absence of external leads reduces parasitic inductance and capacitance compared to gull-wing leaded packages, improving high-frequency performance. This combination of thermal and electrical benefits has made QFN the package of choice across consumer electronics, wireless communications, industrial sensors, and automotive control units.
QFN Package Types: A Comparison
While the QFN concept is consistent, several variants have emerged to serve different manufacturing processes and performance requirements:
| Package Variant | Process Basis | Key Advantage | Typical Use |
| Standard QFN | Leadframe + molding | Low cost, mature supply chain | Consumer ICs, PMIC |
| Organic QFN (OQFN) | Organic substrate | Finer pitch, better signal integrity | RF, telecom, mixed-signal |
| Panel-Level QFN (PL-QFN) | Panel-level packaging | Ultra-low cost at volume | IoT, wearables, automotive |
| Dual-Row QFN | Leadframe | Higher I/O density | Connectivity ICs |
| Thermally Enhanced QFN | Leadframe + thermal slug | Superior heat dissipation | Power semiconductors |
Organic QFN: The High-Performance Alternative
Traditional QFN packages use a metal leadframe as the substrate — a cost-effective approach that suits high-volume commodity ICs. Organic QFN replaces the leadframe with an organic laminate substrate, enabling finer pitch routing, better impedance control, and improved electrical performance for RF and mixed-signal applications.
For RF front-end modules, millimeter-wave components, and precision analog ICs, organic QFN delivers performance characteristics that leadframe-based packages cannot match. The substrate enables multi-layer routing, embedded passive integration, and support for tighter pad pitches demanded by advanced silicon nodes.
PCB Technologies’ iNPACK division has developed deep capabilities in organic QFN manufacturing, offering DFM consultation, rapid prototyping, and scalable production. Their approach ensures that performance-optimized designs translate successfully from simulation to silicon.
Panel-Level Packaging: The Cost Revolution
Wafer-level packaging has long been the benchmark for cost-efficient IC packaging in high-volume production — but it is constrained by wafer diameter. Panel-level packaging applies the same lithographic and encapsulation processes to rectangular panels many times larger than a 300mm wafer, dramatically increasing throughput per equipment cycle.
For QFN-type packages produced at scale, panel-level processing can reduce per-unit cost by 30–50% compared to wafer-level equivalents, depending on die size and panel utilization. This cost structure is transforming the economics of IoT components, wireless modules, and automotive sensor ICs — categories where per-unit price pressure is intense.
Thermal Management in QFN Designs
One of the most critical design decisions when using QFN packages is thermal management at the board level. The exposed thermal pad requires careful PCB design to maximize heat transfer:
- Thermal via arrays beneath the exposed pad are strongly recommended for high-power devices
- Pad size should follow IPC-7351 land pattern guidelines for the specific package
- Solder paste aperture design affects both electrical connection and thermal conductivity
- Adjacent ground planes and copper pours help spread heat away from the die
Poor thermal design with QFN packages can negate their inherent thermal advantage, resulting in premature failure or derating. PCB Technologies provides DFM review as part of their packaging engagement, catching thermal design issues before they reach prototype stage.
QFN vs. QFP: When Each Makes Sense
The most common comparison made against QFN is QFP (Quad Flat Package) — the leaded alternative. Each format has its place:
- QFN: Better for high-frequency applications, tighter board area budgets, and superior thermal performance; requires precision solder printing
- QFP: Easier to inspect visually and rework, more forgiving of PCB assembly tolerances; larger footprint
For new designs targeting advanced nodes and compact form factors, QFN consistently wins the performance-per-area tradeoff. The manufacturing challenge of QFN — particularly solder void management under the thermal pad — is well-understood and manageable with proper process controls.
PCB Technologies’ QFN Capability
PCB Technologies offers end-to-end QFN packaging services through their iNPACK platform, spanning design consultation, substrate development, packaging, and test. Their organic QFN capabilities support pitches not achievable with standard leadframe-based processes, making them a strong partner for next-generation wireless, automotive, and medical IC designs.
With established supply chains for organic substrate materials and a track record across demanding qualification standards, PCB Technologies bridges the gap between the cost efficiency demanded by volume production and the performance requirements of advanced applications.
Conclusion
QFN packages continue to evolve — from standard leadframe variants to organic and panel-level formats that unlock new performance and cost tiers. As silicon advances drive smaller die sizes and higher I/O densities, the packaging layer becomes increasingly critical. Selecting the right QFN variant and working with an experienced packaging partner ensures that board-level performance matches the potential of the silicon within.
-
